It is mainly used for non-stop on line rooting colors and lengths changes up to 7 .

Basic Data :

Spec.: 850 x 1450 x 1750mm

Weight : 400kgs

Voltage ：220V

Power : 7.0KW

Air Pressure : 6 pa

Monitor : available

Controller : typical type

Data Storage : <=20

Non-stop Hair Cut Change : max 7

Non-stop Hair Color Change : max 7

Hand Wheel : available

Laser Positioning : available

Programming : CNC w. Infred Ray

Interact axises : 10

Fiber Break Detection : available

Head Mold : Copper w. Polyster Putty  or 3D printed mold

Application Data :

Head Sizes : 2.5 ~ 15cm (from left ear to right ear)

Head Hardness : Shore 40 ~ 100

Hair Material : Nylon / PP / PE / PVC / PVDC / PET / PBT / Acrylic  etc

Hair Shape : Straight & Curly

Hair Cut : 7.5cm(3") ~ 40cm (16")

Doll Hair Rooting : Workable for single strand or mixed strands

Braid Rooting : max 2mm width

Part Line Rooting : workable

Fiber Lock Type : Interlock

Needle Sizes : 80 / 90 / 100 / 110 /120 / 130 /140 /160 /180#

Rooting Speed : Max 22 stitches / sec

Warranty & Overseas Training Policy

Consumable parts — including, but not limited to, the needle, inner needle tube, needle rod, cutter, screws, bolts, and hair bar — are excluded from warranty coverage. All other main components, such as the motor, servo, screen, and sensors, are covered by a one-year warranty, unless damage or failure is caused by improper operation or accident.

Head molds are available at an additional charge. Should a mold be required, the client must provide at least 12 bald head samples for mold fabrication.

Overseas training conducted by our technician: Airfare is complimentary for orders of two (2) units or more placed in a single batch. Accommodation and meals, however, shall be arranged and borne by the client.
